Model

DH-PFM920I-6UN-C

DH-PFM920I-6UN-U

Structure

Conductor

Material

OFC(oxygen free copper)

Structure

4P*0.53±0.01mm

Insulation

Material

HDPE

Min. average thickness

0.21mm

Diameter

0.95mm0.05mm

Color(4 Pairs)

Orange, white/orange; green, white/green;

blue, white/blue; brown, white/brown

Rip cord

Yes

Jacket

Material

PVC, meet the requirement of CPR E class

PVC, meet the requirement of UL CM class

Min. average thickness

0.40mm

Diameter

6.0±0.50mm

surface

Smooth, full and tight

Color

White

General

Length

305m(1000.66ft)

N.W.

11.25kg(24.8lb)

Packaging dimension

412mmx412mmx215mm(16.22”x16.22”x8.46”)

Weight (with packaging)

12.75kg(28.11lb)

Mechanical properties

Insulation

Tensile strength

≥16MPa

Elongation at break

≥300%

Peeling property

No damage to insulation or conductor

Jacket

Tensile strength

Before aging: ≥13.5MPa

Before aging: ≥13.5MPa

After aging: ≥12.5MPa

Retention rate of tensile strength after aging: ≥85%

Elongation at break

Before aging: ≥150%

Before aging: ≥150%

After aging: ≥125%

Retention rate of elongation at break after aging: ≥50%

Aging condition

100℃*24h*7d

Peeling property

No damage to insulation, cold bending (-20C *4h), the outer diameter of the cable is 8 times, without cracking.

No damage to insulation, cold bending (-15C *4h), the outer diameter of the cable is 8 times, without cracking.

Electrical performance (20℃)

Characteristic impedance (1-250MHz)

100±15Ω

DC resistance

≤9.38Ω/100m

Max. unbalance rate of line pairs’ direct current

≤5%

Time delay
